• RTrak - All-In-One APRS Tracker

Key Features
• APRS Modem (OpenTracker 1+), GPS and Transmitter all built-in
• Transmitter is frequency agile, up to 8 frequencies can be pre-programmed
• Fast GPS lock time - Typically <30 Seconds!
• Small and Lightweight - Size: 123x78x27mm Weight: 206g or 7.25oz
• Aluminum Case Custom Milled and Engraved - Looks good and built to last!
• Free Firmware Upgrades
• Low-loss gold-plated SMA connectors

  The RTrak is the first of it's kind! A true all-in-one APRS tracker with built in 500mW frequency-agile transmitter and Sirf enabled GPS. The transmitter is programmable for any frequency in the range of 144-148 MHz. The transmitter can operate on any of eight pre-programmed frequencies, selectable by an on-board rotary selector switch. Dual frequencies can be used by using dual timers or any of the OpenTracker switch functions (exp: alititude, speed and voltage input) The tracker is based on the popular open source OpenTracker 1+. Firmware upgrades are free and user-flashable.

Weight and Size:
• With Case Weight: 206g or 7.25 oz
• With Case Size: 123x78x27 mm (LxWxH)
• Without Case Weight: 62g or 2.25 oz
• Without Case Size: 120x75x14 mm (LxWxH)

Package Contents
• RTrak APRS Tracker
• Micro Magnetic GPS Patch Antenna
• Programming Cable
• Lighter Plug Power Cord
• Manual

• For more information or updates, please join the RTrak Yahoo group at: http://groups.yahoo.com/group/rtrak/

Notice: This is a pre-order item. Please allow for up to six weeks before delivery

$250.00 + Shipping --- Part #RTRAK

RTrak-LP Ordering is suspended at this time, until we can catch up all current orders. We appologize, but we must catch up all current orders before we can take in any more. Thank you for your understanding!

• Argent Data Systems - OpenTracker 1+

  BRAND NEW! APRS tracker module. The new plus version has all of the features of the original 1x with the addition of software decoding for two-way waypoint operation, better known as the "Anti-Tracker" method. This function allows for decoded position packets to be sent to your mapping GPS as a waypoint to show where other APRS stations are, around you. Open source and freely upgradable through their Windows configuration program. Has larger 7805 voltage regulator to power Deluo style GPS receivers directly. (We recommend Deluo, but just about any GPS that requires 5VDC for power will work) This unit is available Pre-Built and tested by us. Includes case.

Kit: $32.00 + Shipping --- Part #R1200-KIT

Built: $45.00 + Shipping --- Part #R1200-PB

• Argent Data Systems - SMT OpenTracker 1+

  This module has all of the functions of the above OT1+ tracker, but in a micro SMT package. This module is in the form factor of a standard 24 pin DIP module for embedded applications.

Built: $40.00 + Shipping --- Part #ROTSMT
